Airports for X-Plane

Haiphong - Haiphong Catbi

Airport details

CountryVietnam
StateHai Duong Province
RegionVV
AirspaceHanoi Ctr
MunicipalityHaiphong
Elevation4ft (1m)
TimezoneGMT +7
Coordinates20.82070, 106.72446
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeVVCI
IATA codeHPH
FAA coden/a

Communication

No airport communication available for VVCI

Approach frequencies

ILS-cat-IRW07110.118.00mi
3° GSRW07110.118.00mi
Nearby Points of Interest:
The Complex of Yen Tu Monuments and Landscape
-
Cat Ba Island
-
Ha Long Bay

Runway info

Runway 07 / 25
 length3048m (10000ft)
 bearing73° / 253°
 width47m (154ft)
 surfaceasphalt
 blast zone100m (328ft) / 100m (328ft)

Airport layout - taxiway location W2


Taxiway locations

 N1  N4  N7  W2  W3  W4
Parking locations

 GA  Gate

Nearby beacons

codeidentifierdistbearingfrequency
CBICAT BI VOR/DME0.3181°117.40
VDOVANDON VOR/DME40.269°115.40
HLNAM DINH NDB42.7234°304
NAHNAM HA (HANOI) VOR/DME42.9234°115.50
AMGIALAM (HANOI) NDB49.4281°294
NOBNOI BAI (HANOI) VOR/DME55.1294°116.10
KNOI BAI INTL (HANOI) NDB58.1293°230
KWNOI BAI (HANOI) NDB60.3293°320

Departure and arrival routes

Transition altitude9030ft
Transition level10000ft
SID end pointsdistanceoutbound heading
RW07
 TUCH1C, TUCH1A40mi69°
 LOCH1C, LOCH1A16mi126°
 VANU1A16mi181°
 VIBA1D, VIBA1C16mi234°
 VIBA1A43mi234°
 PHUT1A, PHUT1C16mi292°
 GASO1A70mi349°
RW25
 TUCH1B, TUCH1D40mi69°
 LOCH1B16mi126°
 VANU1C119mi176°
 VANU1B16mi181°
 VIBA1B43mi234°
 VIBA1E16mi234°
 PHUT1B16mi292°
 ADMA1A55mi294°
 DOKL1A70mi349°

STAR starting pointsdistanceinbound heading
ALL
 VANU1F16.21°
 NAH1C42.954°
 PHUT1H16.1112°
RW07
 BATO1A, BATO1B, BATO1C36.21°
 NAH1D, NAH1J42.954°
 PHUT1E, PHUT1D16.1112°
 NOB1A55.1114°
RW25
 VANU1E, VANU1D16.21°
 BATO1D36.21°
 NAH1L42.954°
 VIBA1F, VIBA1H16.254°
 PHUT1F, PHUT1G16.1112°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW07-YVANUC (1°)VANUC 3000ft
DUMIM (10mi, 304°)
CI071 (7mi, 342°) 2500ft
 RNAVCI071 2500ft
CI070 (4mi, 73°) 2010ft
VVCI (7mi, 72°) 58ft
(6342mi, 259°) 1000ft
VANUC (6344mi, 79°) 3000ft
VANUC (turn) 3000ft
RW07-ZCI072 (73°)CI072 4000ft
CI071 (7mi, 73°) 2500ft
RW07-ZDAGSA (103°)DAGSA 4600ft
CI071 (7mi, 162°) 2500ft
RW07-ZDUMIM (41°)DUMIM 4000ft
CI071 (7mi, 342°) 2500ft
RW07-ZVIBAO (54°)VIBAO
CI071 (7mi, 21°) 2500ft
 RNAVCI071 2500ft
CI070 (4mi, 73°) 2010ft
VVCI (7mi, 72°) 58ft
(6342mi, 259°) 1000ft
VANUC (6344mi, 79°) 3000ft
VANUC (turn) 3000ft
RW25-YVANUC (1°)VANUC 3000ft
FILET (18mi, 47°)
CI251 (7mi, 341°) 2500ft
 RNAVCI251 2500ft
CI250 (4mi, 253°) 2010ft
VVCI (7mi, 255°) 60ft
(6342mi, 259°) 1000ft
VANUC (6344mi, 79°) 3000ft
VANUC (turn) 3000ft
RW25-ZCI252 (254°)CI252 4000ft
CI251 (7mi, 253°) 2500ft
RW25-ZFILET (285°)FILET 4000ft
CI251 (7mi, 341°) 2500ft
RW25-ZTOMUL (222°)TOMUL 4000ft
CI251 (7mi, 161°) 2500ft
 RNAVCI251 2500ft
CI250 (4mi, 253°) 2010ft
VVCI (7mi, 255°) 60ft
(6342mi, 259°) 1000ft
VANUC (6344mi, 79°) 3000ft
VANUC (turn) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
BATO1AHODOLVHFleft165 (345)°6000ft - 14000ft1.0min timed230
BATO1BHODOLVHFleft165 (345)°6000ft - 14000ft1.0min timed230
BATO1CHODOLVHFleft165 (345)°6000ft - 14000ft1.0min timed230
BATO1DFILETVHFleft164 (344)°4000ft - 14000ft1.0min timed230
BATO1DHODOLVHFleft165 (345)°6000ft - 14000ft1.0min timed230
NAH1CVIBAOVHFright235 (55)°> 4000ft1.0min timedICAO rules
NAH1JNAHNDBleft155 (335)°14000ft - 60000ft1.5min timedICAO rules
NAH1LFILETVHFleft164 (344)°4000ft - 14000ft1.0min timed230
NAH1LNAHNDBleft155 (335)°14000ft - 60000ft1.5min timedICAO rules
PHUT1DPHUTAVHFright297 (117)°6000ft - 14000ft1.0min timed230
PHUT1EPHUTAVHFright297 (117)°6000ft - 14000ft1.0min timed230
PHUT1FPHUTAVHFright297 (117)°6000ft - 14000ft1.0min timed230
PHUT1GPHUTAVHFright297 (117)°6000ft - 14000ft1.0min timed230
VANU1DFILETVHFleft164 (344)°4000ft - 14000ft1.0min timed230
VIBA1FFILETVHFleft164 (344)°4000ft - 14000ft1.0min timed230
*) magnetic outbound (inbound) holding course
