Airports for X-Plane

Subang - Kuala Lumpur S Abdul Aziz Shah

Airport details

CountryMalaysia
StateSelangor
RegionWM
AirspaceKuala Lumpur Ctr
MunicipalityShah Alam
Elevation87ft (27m)
TimezoneGMT +8
Coordinates3.12500, 101.56052
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeWMSA
IATA codeSZB
FAA coden/a

Communication

Kuala Lumpur S Abdul Aziz Shah SUBANG INFO127.600
Kuala Lumpur S Abdul Aziz Shah LUMPUR Clearance126.000
Kuala Lumpur S Abdul Aziz Shah SUBANG Ground Control121.900
Kuala Lumpur S Abdul Aziz Shah SUBANG Tower118.200
Kuala Lumpur S Abdul Aziz Shah LUMPUR DIRECTOR124.200
Kuala Lumpur S Abdul Aziz Shah LUMPUR DIRECTOR118.650

Approach frequencies

ILS-cat-IRW15110.318.00mi
3° GSRW15110.318.00mi

Runway info

Runway 15 / 33
 length3799m (12464ft)
 bearing150° / 330°
 width47m (154ft)
 surfaceasphalt
 blast zone61m (200ft) / 61m (200ft)

Airport layout


Taxiway locations

 A  B  C  D  E  F  J  K
 L  M  N  P  Q  R  T
Parking locations

 Air  Airod  Bay  Cargo  GA  Maint  Maritim

Nearby beacons

codeidentifierdistbearingfrequency
CECALEDONIAN (KUALA LUMPUR) NDB12.1327°205
VBABATU ARANG VOR/DME13.5333°114.70
VSPSEPANG VOR/DME23.3164°114.40
VKLKUALA LUMPUR VOR/DME26.3156°116.10
VMKMALACCA VOR/DME66.3142°117.40

Departure and arrival routes

Transition altitude11000ft
Transition level13000ft
SID end pointsdistanceoutbound heading
RW15
 PULI1T, PULI1S39mi32°
 MATS1S, MATS1T38mi60°
 PIBO1L33mi65°
 ADNU1T, ADNU1S65mi78°
 KIMA1T, KIMA1S, KIMA1L47mi87°
 GUPTA87mi132°
 RUSB1L87mi139°
 BATA1S66mi151°
 DUMO1S56mi152°
 MITO1S, MITO1L76mi155°
 VKL26mi156°
 RUMI1S47mi177°
 SALA1L55mi180°
 AGOSA21mi273°
 PUGE1L78mi282°
 BILI1S, BILI1T29mi297°
 IBUK1L55mi301°
 SUKA1S, SUKA1T43mi311°
 ATIM1L48mi313°
 BIKD1L44mi349°
RW33
 GUPTA87mi132°
 BATAR66mi151°
 VKL26mi156°
 BILIKA, BILIKB29mi297°
 SUKAT43mi311°

STAR starting pointsdistanceinbound heading
RW15
 PUGE1M77.7102°
 NIRE1M64.7110°
 KAKA1M43.4153°
 PULI1M38.6212°
 SARO1M69.4286°
 GUPT1M86.8312°
 SALA1M55.1360°
