Airports for X-Plane

Melbourne - Avalon

Airport details

CountryAustralia
StateVictoria
RegionYM
AirspaceMelbourne Ctr
MunicipalityCity of Greater Geelong
Elevation35ft (11m)
TimezoneGMT +10
Coordinates-38.02630, 144.48067
Magnetic var
Typeland
Available sinceX-Plane v10.32
ICAO codeYMAV
IATA codeAVV
FAA coden/a

Communication

Avalon Avalon ATIS118.200
Avalon Avalon Tower120.100
Avalon Avalon Approach133.550

Approach frequencies

ILS-cat-IRW18109.518.00mi
3° GSRW18109.518.00mi

Runway info

Runway 18 / 36
 length3051m (10010ft)
 bearing189° / 9°
 width45m (148ft)
 surfaceasphalt
 blast zone243m (797ft) / 255m (837ft)

Airport layout - parking location International


Taxiway locations

 A  B  C  D
Parking locations

 International  Maint  New  Terminal

Nearby beacons

codeidentifierdistbearingfrequency
AVAVALON VOR/DME1.7224°116.10
MLMELBOURNE VOR/DME27.845°114.10
MBMOORABBIN (MELBOURNE) NDB2985°398

Departure and arrival routes

Transition altitude10000ft
Transition level11000ft
SID end pointsdistanceoutbound heading
RW18
 JUSTY228mi45°
RW36
 JUSTY228mi45°

STAR starting pointsdistanceinbound heading
RW18
 JAYBI523.2188°
RW36
 JAYBI523.2188°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW18AVVND (221°)AVVND 3700ft
AVVNI (6mi, 260°) 2950ft
RW18AVVNE (187°)AVVNE 3700ft
AVVNI (6mi, 190°) 2950ft
 RNAVAVVNI 2950ft
AVVNF (3mi, 190°) 2090ft
AVVNM (6mi, 190°) 82ft
AVVNH (2mi, 190°)
(7798mi, 285°) 3000ft
RW36-ZAVVSA (34°)AVVSA 3000ft
AVVSI (4mi, 73°) 2180ft
RW36-ZAVVSB (13°)AVVSB 3000ft
AVVSI (3mi, 10°) 2180ft
RW36-ZAVVSC (350°)AVVSC 3000ft
AVVSI (4mi, 300°) 2180ft
 RNAVAVVSI 2180ft
AVVSF (3mi, 10°) 1360ft
AVVSM (4mi, 10°) 86ft
AVVSH (2mi, 10°)
(7800mi, 285°) 3000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
JAYBI5APPLEVHFleft300 (120)°20000ft - 60000ft1.5min timedICAO rules
JAYBI5CANTYVHFright339 (159)°< 60000ft1.0min timedICAO rules
JAYBI5TEMPLVHFleft356 (176)°DME 4.0miICAO rules
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
