Country | China |
State | Zhejiang |
Region | ZS |
Airspace | Shanghai Ctr |
Municipality | Wenzhou |
Elevation | 16ft (5m) |
Timezone | GMT +8 |
Coordinates | 27.91000, 120.85333 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | ZSWZ |
IATA code | WNZ |
FAA code | n/a |
Wenzhou Longwan Intl ATIS | 127.050 |
Wenzhou Longwan Intl Wenzhou Ground | 121.850 |
Wenzhou Longwan Intl Wenzhou Tower | 118.875 |
Wenzhou Longwan Intl Wenzhou Approach 01 | 119.625 |
Wenzhou Longwan Intl Wenzhou Approach 02 | 120.250 |
Wenzhou Longwan Intl Wenzhou Approach 03 | 127.975 |
Wenzhou Longwan Intl Wenzhou Approach STBY | 132.150 |
ILS-cat-I | RW03 | 110.3 | 18.00mi |
ILS-cat-I | RW21 | 108.7 | 18.00mi |
3° GS | RW03 | 110.3 | 18.00mi |
3° GS | RW21 | 108.7 | 18.00mi |
Runway 03 / 21 | ||
length | 3203m (10509ft) | |
bearing | 31° / 211° | |
width | 45m (148ft) | |
surface | concrete | |
blast zone | 60m (197ft) / 60m (197ft) |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
WNZ | WENZHOU VOR/DME | 1.2 | 31° | 116.40 |
DST | DONGSHAN VOR/DME | 15.2 | 234° | 109.20 |
Transition altitude | 9843ft |
Transition level | 11811ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW03 | |||
BEG52X, BEG51X, BEG13D, BEG11D | 52mi | 85° | |
OKA52X, OKA51X, OKA13D, OKA11D | 43mi | 114° | |
LJG52X, LJG51X, LJG13D, LJG11D | 123mi | 218° | |
BZ52X, BZ51X, BZ13D, BZ11D | 69mi | 278° | |
SHZ53X, SHZ52X, SHZ51X, SHZ15D, SHZ13D, SHZ11D | 102mi | 359° | |
RW21 | |||
BEG62X, BEG61X, BEG12D | 52mi | 85° | |
OKA62X, OKA61X, OKA12D | 43mi | 114° | |
LJG62X, LJG61X, LJG12D | 123mi | 218° | |
BZ61X, BZ14D, BZ12D | 69mi | 278° | |
SHZ12D, SHZ14D, SHZ16D, SHZ61X | 102mi | 359° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW03 | |||
LJG01A, LJG51F, LJG52F | 123.1 | 38° | |
BZ01A, BZ51F | 69.4 | 98° | |
SHZ01A, SHZ51F, SHZ03A | 101.5 | 179° | |
BEG01A, BEG51F | 52.2 | 265° | |
OKA51F, OKA01A | 43.1 | 294° | |
RW21 | |||
LJG62F, LJG61F, LJG04A, LJG02A | 123.1 | 38° | |
BZ63F, BZ62F, BZ61F, BZ04A, BZ02A | 69.4 | 98° | |
SHZ04A, SHZ02A, SHZ61F, SHZ62F, SHZ06A | 101.5 | 179° | |
BEG04A, BEG61F, BEG02A | 52.2 | 265° | |
OKA61F, OKA02A | 43.1 | 294° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BEG01A | CHARE | VHF | left | 81 (261)° | > 6890ft | 1.0min timed | 215 |
BEG02A | CHARE | VHF | left | 81 (261)° | > 6890ft | 1.0min timed | 215 |
BEG02A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
BEG51F | WZ508 | VHF | left | 32 (212)° | 1.0min timed | 215 | |
BEG61F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
BZ01A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
BZ02A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
BZ02A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
BZ51F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
BZ61F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
BZ61F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
BZ62F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
LJG01A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
LJG02A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
LJG02A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
LJG04A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
LJG51F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
LJG61F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
LJG61F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
LJG62F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
OKA01A | A | NDB | left | 153 (333)° | > 3940ft | 1.0min timed | 215 |
OKA02A | A | NDB | left | 153 (333)° | > 3940ft | 1.0min timed | 215 |
OKA02A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
OKA51F | WZ508 | VHF | left | 32 (212)° | 1.0min timed | 215 | |
OKA61F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
SHZ01A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
SHZ02A | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
SHZ02A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
SHZ03A | WNZ | NDB | left | 19 (199)° | > 4930ft | 1.0min timed | 215 |
SHZ51F | DST | NDB | right | 285 (105)° | > 4930ft | 1.0min timed | 215 |
SHZ61F | WZ605 | VHF | left | 212 (32)° | 1.0min timed | 215 | |
*) magnetic outbound (inbound) holding course |
