Country | United Kingdom |
State | Wales |
Region | EG |
Airspace | London Ctr |
Municipality | Flintshire |
Elevation | 42ft (13m) |
Timezone | GMT +0 |
Coordinates | 53.17805, -2.97778 |
Magnetic var | |
Type | land |
Available since | X-Plane v11.33 |
ICAO code | EGNR |
IATA code | CEG |
FAA code | n/a |
Hawarden Tower | 124.950 |
Hawarden unnamed entity | 128.800 |
Hawarden Approach | 123.350 |
ILS-cat-I | RW22 | 110.35 | 18.00mi |
ILS-cat-I | RW04 | 110.35 | 18.00mi |
3.5° GS | RW04 | 110.35 | 18.00mi |
3° GS | RW22 | 110.35 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
HAW | HAWARDEN NDB | 0 | 302° | 340 |
WHI | WHITEGATE NDB | 12.7 | 89° | 368 |
LPL | LIVERPOOL NDB | 13.2 | 57° | 349 |
WAL | WALLASEY VOR/DME | 14 | 324° | 114.10 |
SWB | SHAWBURY VOR/DME | 25.5 | 140° | 116.80 |
MCT | MANCHESTER VOR/DME | 27.8 | 76° | 113.55 |
WPL | WELSHPOOL NDB | 33.5 | 198° | 323 |
WTN | WARTON TACAN | 34 | 9° | 113.20 |
WTN | WARTON NDB | 34.7 | 12° | 337 |
BPL | BLACKPOOL NDB | 35.7 | 355° | 318 |
POL | POLE HILL VOR/DME | 46.1 | 57° | 112.10 |
WBA | WOLVERHAMPTON NDB | 47.4 | 133° | 356 |
WOL | DME | 47.5 | 133° | 108.60 |
SH | SHOBDON NDB | 56.2 | 174° | 426 |
WL | BARROW (WALNEY ISLAND) NDB | 57.9 | 343° | 385 |
Transition altitude | 5000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW04 | |||
WAL4 | 14mi | 324° | |
RW22 | |||
WAL4 | 14mi | 324° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
KEGU1D | 18.5 | 35° | |
KEGU2B | 47.7 | 275° | |
KEGU2A | 73.7 | 283° | |
KEGU2C | 52.3 | 289° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
KEGU1D | KEGUN | VHF | left | 184 (4)° | 1.0min timed | ICAO rules | |
KEGU2A | KEGUN | VHF | left | 184 (4)° | 1.0min timed | ICAO rules | |
KEGU2B | KEGUN | VHF | left | 184 (4)° | 1.0min timed | ICAO rules | |
KEGU2C | KEGUN | VHF | left | 184 (4)° | 1.0min timed | ICAO rules | |
*) magnetic outbound (inbound) holding course |
