Airports for X-Plane

Shelbyville - Shelbyville Muni

Airport details

CountryUnited States of America
StateIndiana
RegionK5
AirspaceIndianapolis Ctr
MunicipalityShelbyville
Elevation801ft (244m)
TimezoneGMT -5
Coordinates39.58314, -85.80480
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeKGEZ
IATA coden/a
FAA codeGEZ

Communication

Shelbyville Muni ASOS121.550
Shelbyville Muni CTAF/UNICOM122.800
Shelbyville Muni INDIANAPOLIS Approach/Departure127.150

Runway info

Runway 1 / 19
 length1525m (5003ft)
 bearing6° / 186°
 width30m (100ft)
 surfaceasphalt
Runway 09 / 27
 length820m (2690ft)
 bearing90° / 270°
 width58m (190ft)
 surfacegrass
 displ threshold139m (456ft) / 88m (289ft)

Airport layout - parking location South


Parking locations

 Army  North  South

Nearby beacons

codeidentifierdistbearingfrequency
SHBSHELBYVILLE VOR/DME3.1338°112
BACLIFS (COLUMBUS) NDB15.6183°410
COCOLFA (INDIANAPOLIS) NDB18.1281°232
FVLAREZ (INDIANAPOLIS) NDB21.8297°349
UMPMETROPOLITAN (INDIANAPOLIS) NDB24.1325°338
UWLNEW CASTLE NDB28.659°385
HLBBATESVILLE NDB29113°254
VHPBRICKYARD VORTAC29.4292°116.30
AIVIDEO (ANDERSON) NDB32.231°394
SQPNTHR (CONNERSVILLE) NDB33.274°227
JNBALLL (MUNCIE) NDB42.239°365
MIBALLL (MUNCIE) NDB42.239°365
MIEMUNCIE VOR/DME43.632°114.40
OOMHOOSIER (BLOOMINGTON) VORTAC45.8241°110.20
RIDRICHMOND VOR/DME45.880°110.60
GVR(MADISON) DME51.9158°114.65
AWWWINCHESTER NDB53.756°212
MZZMARION VOR/DME54.98°108.60
OKKKOKOMO VORTAC57.9345°113.50

Departure and arrival routes

Transition altitude18000ft
Transition level18000ft
SID end pointsdistanceoutbound heading
RW01
 MAREO576mi77°
 DAWNN1104mi195°
 OOM5135mi230°
 ROCKY1222mi261°
 MEARZ658mi345°
RW19
 MAREO576mi77°
 DAWNN1104mi195°
 OOM5135mi230°
 ROCKY1222mi261°
 MEARZ658mi345°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW01SHB (158°)SHB
WAGSE (16mi, 181°) 3000ft
WAGSE (turn) 3000ft
 RNAVWAGSE 3000ft
JURLA (8mi, 6°) 2500ft
KGEZ (5mi, 6°) 846ft
(5211mi, 115°) 1203ft
DOTYY (5211mi, 295°) 3000ft
DOTYY (turn)
RW19HOMAR (208°)HOMAR
DOTYY (10mi, 231°) 3000ft
RW19OPVAF (214°)OPVAF
DOTYY (5mi, 274°) 3000ft
RW19SHB (158°)SHB
DOTYY (9mi, 15°) 3000ft
DOTYY (turn) 3000ft
RW19ZAVNE (130°)ZAVNE
EKUZE (11mi, 104°) 3000ft
DOTYY (5mi, 93°) 3000ft
 RNAVDOTYY 3000ft
LISTE (6mi, 186°) 2500ft
KGEZ (6mi, 186°) 847ft
(5211mi, 115°) 1095ft
WAGSE (5211mi, 295°) 3000ft
WAGSE (turn)
