Country | United States of America |
State | Massachusetts |
Region | K6 |
Airspace | Boston Ctr |
Municipality | Barnstable |
Elevation | 55ft (17m) |
Timezone | GMT -5 |
Coordinates | 41.66933, -70.28036 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.35 |
ICAO code | KHYA |
IATA code | HYA |
FAA code | HYA |
Barnstable Muni ATIS | 123.800 |
Barnstable Muni CTAF | 119.500 |
Barnstable Muni UNICOM | 122.950 |
Barnstable Muni Clearance and Delivery | 125.150 |
Barnstable Muni Ground | 118.450 |
Barnstable Muni Tower | 119.500 |
Barnstable Muni Boston Aproach and Departure | 118.200 |
ILS-cat-I | RW15 | 108.95 | 18.00mi |
ILS-cat-I | RW24 | 109.15 | 18.00mi |
3.1° GS | RW15 | 108.95 | 18.00mi |
3° GS | RW24 | 109.15 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
HY | BOGEY (HYANNIS) NDB | 4.4 | 59° | 342 |
FMH | OTIS (FALMOUTH) TACAN | 10.4 | 268° | 115.80 |
CQX | NAUSET (CHATHAM) NDB | 13.1 | 86° | 279 |
MVY | MARTHA'S VINEYARD VOR/DME | 22.1 | 231° | 114.50 |
LFV | MARCONI (NORTH TRURO) VOR/DME | 23.5 | 35° | 114.70 |
PVC | PROVINCETOWN NDB | 24.1 | 8° | 389 |
ACK | NANTUCKET VOR/DME | 25.9 | 147° | 116.20 |
OW | STOGE (NORWOOD) NDB | 46.5 | 298° | 397 |
BOS | BOSTON VOR/DME | 52 | 314° | 112.70 |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW06 | ACK (327°) | ACK LULIY (21mi, 296°) 2000ft FIXUG (5mi, 312°) 2000ft |
RW06 | FIXUG (57°) | FIXUG 2000ft |
RW06 | GAILS (149°) | GAILS JEBIM (18mi, 210°) 3000ft FIXUG (5mi, 131°) 2000ft |
RW06 | HOPTU (98°) | HOPTU JEBIM (24mi, 111°) 2000ft FIXUG (5mi, 131°) 2000ft |
RW06 | MVY (51°) | MVY FIXUG (10mi, 42°) 2000ft |
RW06 | TUTOR (89°) | TUTOR JEBIM (18mi, 98°) 2000ft FIXUG (5mi, 131°) 2000ft |
RNAV | FIXUG 2000ft COVOD (6mi, 58°) 2000ft KHYA (6mi, 56°) 81ft (4528mi, 121°) 316ft MECEJ (4523mi, 301°) 1700ft MECEJ (turn) | |
RW15 | BOS (134°) | BOS DUCEG (40mi, 135°) 2000ft |
RW15 | LFV (215°) | LFV ALOTY (17mi, 248°) 2000ft DUCEG (5mi, 238°) 2000ft |
RW15 | MVY (51°) | MVY DUCEG (27mi, 20°) 2000ft DUCEG (turn) 2000ft |
RNAV | DUCEG 2000ft KENAD (6mi, 131°) 2000ft KHYA (6mi, 130°) 109ft BOWLE (4mi, 134°) COOKK (6mi, 82°) LFV (23mi, 8°) 2000ft LFV (turn) | |
RW24 | DONNN (238°) | DONNN 1700ft |
RW24 | LFV (215°) | LFV NOVCE (11mi, 215°) 1700ft DONNN (5mi, 132°) 1700ft |
RW24 | SOFOB (258°) | SOFOB DONNN (5mi, 312°) 1700ft |
RNAV | DONNN 1700ft ASHIP (6mi, 238°) 1700ft KHYA (6mi, 239°) 89ft FIXUG (12mi, 237°) 2000ft FIXUG (turn) | |
RW33 | ACK (327°) | ACK VIGYU (13mi, 343°) 2000ft |
RW33 | LFV (215°) | LFV HOXUD (26mi, 171°) 2000ft VIGYU (8mi, 238°) 2000ft |
RW33 | MVY (51°) | MVY JANIR (18mi, 86°) 2000ft VIGYU (7mi, 58°) 2000ft |
RNAV | VIGYU 2000ft ZASAB (7mi, 312°) 2000ft KHYA (6mi, 313°) 103ft (4528mi, 121°) 293ft DUCEG (4538mi, 301°) 2000ft DUCEG (turn) |
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
