Country | United States of America |
State | Georgia |
Region | K7 |
Airspace | Atlanta Ctr |
Municipality | Cobb County |
Elevation | 1066ft (325m) |
Timezone | GMT -5 |
Coordinates | 33.91953, -84.52612 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | KMGE |
IATA code | MGE |
FAA code | MGE |
DOBBINS ARB Ground Control | 125.300 |
DOBBINS ARB Tower | 120.750 |
DOBBINS ARB ATLANTA Approach/Departure | 121.000 |
ILS-cat-I | RW11 | 109.7 | 18.00mi |
ILS-cat-I | RW29 | 111.35 | 18.00mi |
3° GS | RW11 | 109.7 | 18.00mi |
3° GS | RW29 | 111.35 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
DOB | DOBBINS (MARIETTA) TACAN | 0.9 | 105° | 113 |
PDK | PEACHTREE (ATLANTA) VOR/DME | 11.6 | 101° | 116.60 |
AT | CATTA (ATLANTA) NDB | 16.3 | 183° | 375 |
ATL | ATLANTA VORTAC | 18 | 163° | 116.90 |
DJD | CHERO NDB | 20 | 7° | 415 |
RMG | ROME VORTAC | 32.9 | 292° | 115.40 |
TX | GWNET (LAWRENCEVILLE) NDB | 33.5 | 81° | 419 |
FKV | FLOWERY BRANCH (GAINESVILLE) NDB | 35.2 | 65° | 365 |
GPQ | CARROLLTON NDB | 36.9 | 240° | 278 |
FFC | PECAT (ATLANTA) NDB | 37.2 | 176° | 316 |
EQQ | COWETA COUNTY (NEWNAN) NDB | 40.8 | 196° | 234 |
VOF | ALCOVY (COVINGTON) NDB | 41 | 111° | 370 |
BMW | BARROW COUNTY (WINDER) NDB | 46.6 | 89° | 404 |
LGC | LA GRANGE VORTAC | 62.3 | 218° | 115.60 |
Transition altitude | 18000ft |
Transition level | 18000ft |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
DIFFI4 | 62.3 | 38° | |
BOKRT3 | 50.2 | 43° | |
SWTEE2 | 31.1 | 94° | |
BUKHD3 | 45.1 | 134° | |
DEHAN3 | 43.1 | 224° | |
WRGNZ3 | 53.6 | 302° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW11 | BATLL (103°) | BATLL 3000ft |
RNAV | BATLL 3000ft CIPEL (6mi, 104°) 2900ft KMGE (6mi, 103°) 1123ft (5132mi, 112°) 2000ft BATLL (5144mi, 292°) 3000ft BATLL (turn) | |
RW29 | BEVBE (284°) | BEVBE 4000ft |
RNAV | BEVBE 4000ft JIDOR (turn) 4000ft HEPAT (3mi, 284°) 3000ft KMGE (7mi, 284°) 1048ft (5132mi, 112°) 2000ft CYLON (5142mi, 292°) 3000ft CYLON (turn) 4000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BUKHD3 | HLNDS | VHF | right | 327 (147)° | DME 10.0mi | ICAO rules | |
DEHAN3 | AWSON | VHF | left | 29 (209)° | DME 10.0mi | ICAO rules | |
DEHAN3 | TRALZ | VHF | right | 32 (212)° | DME 10.0mi | ICAO rules | |
DIFFI4 | LGC | NDB | right | 228 (48)° | 1.0min timed | ICAO rules | |
SWTEE2 | BIZKT | VHF | left | 292 (112)° | DME 10.0mi | ICAO rules | |
*) magnetic outbound (inbound) holding course |
