Marietta - Dobbins Arb
Airport details
| Country | United States of America |
| State | Georgia |
| Region | K7 |
| Airspace | Atlanta Ctr |
| Municipality | Cobb County |
| Elevation | 1066ft (325m) |
| Timezone | GMT -5 |
| Coordinates | 33.91953, -84.52612 |
| Magnetic var | |
| Type | land |
| Available since | X-Plane v10.40 |
| ICAO code | KMGE |
| IATA code | MGE |
| FAA code | MGE |
Communication
| DOBBINS ARB Ground Control | 125.300 |
| DOBBINS ARB Tower | 120.750 |
| DOBBINS ARB ATLANTA Approach/Departure | 121.000 |
Approach frequencies
| ILS-cat-I | RW11 | 109.7 | 18.00mi |
| ILS-cat-I | RW29 | 111.35 | 18.00mi |
| 3° GS | RW11 | 109.7 | 18.00mi |
| 3° GS | RW29 | 111.35 | 18.00mi |
Nearby beacons
| code | identifier | dist | bearing | frequency |
|---|---|---|---|---|
| DOB | DOBBINS (MARIETTA) TACAN | 0.9 | 105° | 113 |
| PDK | PEACHTREE (ATLANTA) VOR/DME | 11.6 | 101° | 116.60 |
| AT | CATTA (ATLANTA) NDB | 16.3 | 183° | 375 |
| ATL | ATLANTA VORTAC | 18 | 163° | 116.90 |
| DJD | CHERO NDB | 20 | 7° | 415 |
| RMG | ROME VORTAC | 32.9 | 292° | 115.40 |
| TX | GWNET (LAWRENCEVILLE) NDB | 33.5 | 81° | 419 |
| FKV | FLOWERY BRANCH (GAINESVILLE) NDB | 35.2 | 65° | 365 |
| GPQ | CARROLLTON NDB | 36.9 | 240° | 278 |
| FFC | PECAT (ATLANTA) NDB | 37.2 | 176° | 316 |
| EQQ | COWETA COUNTY (NEWNAN) NDB | 40.8 | 196° | 234 |
| VOF | ALCOVY (COVINGTON) NDB | 41 | 111° | 370 |
| BMW | BARROW COUNTY (WINDER) NDB | 46.6 | 89° | 404 |
| LGC | LA GRANGE VORTAC | 62.3 | 218° | 115.60 |
Departure and arrival routes
| Transition altitude | 18000ft |
| Transition level | 18000ft |
| STAR starting points | distance | inbound heading | |
|---|---|---|---|
| ALL | |||
| DIFFI4 | 62.3 | 38° | |
| BOKRT3 | 50.2 | 43° | |
| SWTEE2 | 31.1 | 94° | |
| BUKHD3 | 45.1 | 134° | |
| DEHAN3 | 43.1 | 224° | |
| WRGNZ3 | 53.6 | 302° | |
Instrument approach procedures
| runway | airway (heading) | route (dist, bearing) |
|---|---|---|
| RW11 | BATLL (103°) | BATLL 3000ft |
| RNAV | BATLL 3000ft CIPEL (6mi, 104°) 2900ft KMGE (6mi, 103°) 1123ft (5132mi, 112°) 2000ft BATLL (5144mi, 292°) 3000ft BATLL (turn) | |
| RW29 | BEVBE (284°) | BEVBE 4000ft |
| RNAV | BEVBE 4000ft JIDOR (turn) 4000ft HEPAT (3mi, 284°) 3000ft KMGE (7mi, 284°) 1048ft (5132mi, 112°) 2000ft CYLON (5142mi, 292°) 3000ft CYLON (turn) 4000ft |
Holding patterns
| STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
|---|---|---|---|---|---|---|---|
| BUKHD3 | HLNDS | VHF | right | 327 (147)° | DME 10.0mi | ICAO rules | |
| DEHAN3 | AWSON | VHF | left | 29 (209)° | DME 10.0mi | ICAO rules | |
| DEHAN3 | TRALZ | VHF | right | 32 (212)° | DME 10.0mi | ICAO rules | |
| DIFFI4 | LGC | NDB | right | 228 (48)° | 1.0min timed | ICAO rules | |
| SWTEE2 | BIZKT | VHF | left | 292 (112)° | DME 10.0mi | ICAO rules | |
| *) magnetic outbound (inbound) holding course | |||||||
Disclaimer
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
