Country | Spain |
State | Extremadura |
Region | LE |
Airspace | Madrid Ctr |
Municipality | Badajoz |
Elevation | 606ft (185m) |
Timezone | GMT +1 |
Coordinates | 38.88488, -6.81775 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.35 |
ICAO code | LEBZ |
IATA code | BJZ |
FAA code | n/a |
Badajoz- Talavera La Real Tower CIVIL | 122.100 |
ILS-cat-I | RW31 | 110.5 | 18.00mi |
3° GS | RW31 | 110.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
VBZ | BADAJOZ VOR/DME | 0.3 | 22° | 116.80 |
TBC | BADAJOZ TACAN | 0.4 | 352° | 108.80 |
CCS | CACERES VOR/DME | 42.3 | 31° | 114.20 |
Transition altitude | 6000ft |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW31 | |||
CCS2A | 42.3 | 211° | |
SVL2E | 100.7 | 324° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
CCS2A | NIMAS | VHF | right | 87 (267)° | > 4500ft | DME 5.0mi | ICAO rules |
SVL2E | VASOR | VHF | right | 177 (357)° | > 4500ft | DME 5.0mi | ICAO rules |
*) magnetic outbound (inbound) holding course |
