Country | Switzerland |
State | Zurich |
Region | LS |
Airspace | Switzerland Ctr |
Municipality | Kloten |
Elevation | 1416ft (432m) |
Timezone | GMT +1 |
Coordinates | 47.45814, 8.57186 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | LSZH |
IATA code | ZRH |
FAA code | n/a |
Zurich ATIS | 128.525 |
Zurich ATIS Arrival | 125.730 |
Zurich ATIS Departure | 129.005 |
Zurich DEL | 121.925 |
Zurich Ground Control | 121.900 |
Zurich APRON S | 121.750 |
Zurich APRON N | 127.750 |
Zurich Tower | 118.100 |
Zurich Departure | 125.955 |
ILS-cat-III | RW14 | 111.75 | 18.00mi |
ILS-cat-III | RW16 | 110.5 | 18.00mi |
ILS-cat-I | RW34 | 110.75 | 18.00mi |
ILS-cat-I | RW28 | 109.75 | 18.00mi |
3.3° GS | RW34 | 110.75 | 18.00mi |
3.3° GS | RW28 | 109.75 | 18.00mi |
3° GS | RW14 | 111.75 | 18.00mi |
3° GS | RW16 | 110.5 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
KLO | KLOTEN (ZURICH) VOR/DME | 1 | 268° | 114.85 |
ZUE | ZURICH EAST VOR/DME | 12.8 | 61° | 110.05 |
TRA | DME | 14.9 | 330° | 114.30 |
WIL | WILLISAU VOR/DME | 31.8 | 247° | 116.90 |
HOC | DME | 36.8 | 271° | 113.20 |
FHD | DME | 39.8 | 77° | 112.60 |
SUL | SULZ VOR | 55.5 | 5° | 116.10 |
LHR | LAHR NDB | 61.6 | 319° | 337 |
LRD | DME | 62.1 | 321° | 108.05 |
Transition altitude | 7000ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW10 | |||
ZUE2D | 13mi | 61° | |
DEGE2E, DEGE1B | 26mi | 94° | |
GERS1E, GERS2C | 25mi | 185° | |
WIL3C, WIL2D | 32mi | 247° | |
VEBI3E, VEBI1B | 26mi | 251° | |
RW16 | |||
DEGE1T, DEGE2R, DEGE3S | 26mi | 94° | |
GERS2S | 25mi | 185° | |
WIL3Q | 32mi | 247° | |
VEBI4S, VEBI1T | 26mi | 251° | |
RW28 | |||
ZUE3V | 13mi | 61° | |
DEGE1X, DEGE1Y, DEGE3W | 26mi | 94° | |
GERS2W | 25mi | 185° | |
VEBI4W, VEBI1Y, VEBI1X | 26mi | 251° | |
RW32 | |||
ZUE5L | 13mi | 61° | |
DEGE5L, DEGE4N, DEGE1P | 26mi | 94° | |
GERS1N | 25mi | 185° | |
VEBI4N | 26mi | 251° | |
RW34 | |||
ZUE5F | 13mi | 61° | |
DEGE1J, DEGE5F, DEGE4H | 26mi | 94° | |
GERS1H | 25mi | 185° | |
VEBI2K, VEBI4H | 26mi | 251° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
ALL | |||
DOPI2G | 32.4 | 55° | |
BERS2G | 32.1 | 63° | |
WIL3Z | 31.8 | 67° | |
TRA2A | 14.9 | 150° | |
RILA2A | 29.2 | 173° | |
KELI3G | 31.1 | 339° |
runway | airway (heading) | route (dist, bearing) |
---|---|---|
RW14 | AMIKI (256°) | AMIKI ZUE (9mi, 275°) ZH411 (6mi, 284°) 7000ft TRA (10mi, 284°) 5000ft ZH413 (5mi, 238°) 4000ft |
RW14 | GIPOL (95°) | GIPOL 7000ft ZH412 (10mi, 65°) 6000ft ZH413 (5mi, 73°) 4000ft |
RW14 | RILAX (173°) | RILAX EDUMI (11mi, 197°) 7000ft TRA (4mi, 197°) 5000ft ZH413 (5mi, 238°) 4000ft |
RNAV | ZH413 4000ft OSNEM (4mi, 126°) 4000ft LSZH (10mi, 126°) 1452ft ZH415 (3mi, 128°) ZH416 (5mi, 53°) 4000ft ZH417 (5mi, 23°) ZUE (4mi, 65°) 6000ft AMIKI (9mi, 95°) 7000ft | |
RW28 | AMIKI (256°) | AMIKI ZH382 (17mi, 304°) ZH450 (7mi, 257°) ZH452 (4mi, 163°) ZH454 (12mi, 119°) ZH456 (5mi, 94°) ZH458 (5mi, 94°) ZH460 (7mi, 189°) 7000ft ZH464 (5mi, 274°) RAMEM (4mi, 274°) 5000ft |
RW28 | GIPOL (95°) | GIPOL ZH445 (6mi, 60°) ZH447 (9mi, 135°) ZH449 (7mi, 135°) ZH451 (7mi, 94°) ZH453 (5mi, 94°) ZH455 (5mi, 94°) ZH457 (5mi, 94°) ZH459 (5mi, 94°) ZH460 (7mi, 9°) 7000ft ZH464 (5mi, 274°) RAMEM (4mi, 274°) 5000ft |
RW28 | RILAX (173°) | RILAX ZH446 (5mi, 163°) ZH448 (4mi, 163°) ZH450 (4mi, 163°) ZH452 (4mi, 163°) ZH454 (12mi, 119°) ZH456 (5mi, 94°) ZH458 (5mi, 94°) ZH460 (7mi, 189°) 7000ft ZH464 (5mi, 274°) RAMEM (4mi, 274°) 5000ft |
RNAV | RAMEM 5000ft LSZH (10mi, 275°) 1467ft ZH465 (5mi, 273°) 4000ft ZH466 (8mi, 203°) ZH467 (12mi, 252°) ZH468 (8mi, 289°) GIPOL (12mi, 22°) 7000ft |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
BERS2G | BERSU | VHF | right | 229 (49)° | 10000ft - 20000ft | 1.0min timed | 230 |
BERS2G | GIPOL | VHF | right | 258 (78)° | 7000ft - 24000ft | 1.0min timed | 230 |
BLM3G | GIPOL | VHF | right | 258 (78)° | 7000ft - 24000ft | 1.0min timed | 230 |
DOPI2G | GIPOL | VHF | right | 258 (78)° | 7000ft - 24000ft | 1.0min timed | 230 |
KELI3G | GIPOL | VHF | right | 258 (78)° | 7000ft - 24000ft | 1.0min timed | 230 |
KELI3G | MOSIT | VHF | right | 171 (351)° | 14000ft - 20000ft | 1.0min timed | 230 |
NEGR2A | AMIKI | VHF | right | 94 (274)° | 7000ft - 24000ft | 1.0min timed | 230 |
RILA2A | AMIKI | VHF | right | 94 (274)° | 7000ft - 24000ft | 1.0min timed | 230 |
RILA2A | RILAX | VHF | right | 8 (188)° | 7000ft - 24000ft | 1.0min timed | ICAO rules |
TRA2A | AMIKI | VHF | right | 94 (274)° | 7000ft - 24000ft | 1.0min timed | 230 |
WIL3Z | GIPOL | VHF | right | 258 (78)° | 7000ft - 24000ft | 1.0min timed | 230 |
*) magnetic outbound (inbound) holding course |
