Airports for X-Plane

Cayo Largo Del Sur - Vilo Acuna Intl

Airport details

CountryCuba
StateIsle of Youth
RegionMU
AirspaceHavana Ctr
Elevation7ft (2m)
TimezoneGMT -5
Coordinates21.61611, -81.54556
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeMUCL
IATA codeCYO
FAA coden/a

Communication

Vilo Acuna Intl CAYO LARGO Tower118.500
Vilo Acuna Intl CAYO LARGO Approach120.100

Runway info

Runway 12 / 30
 length2993m (9820ft)
 bearing115° / 295°
 width45m (148ft)
 surfaceasphalt
 blast zone60m (197ft) / 60m (197ft)

Airport layout - taxiway location B


Taxiway locations

 A  B  C
Parking locations

 GA  Terminal

Nearby beacons

codeidentifierdistbearingfrequency
UCLCAYO LARGO DEL SUR VOR/DME0.9131°112.10

Departure and arrival routes

Transition altitude3000ft
SID end pointsdistanceoutbound heading
RW12
 VARC3A63mi8°
 YANT2A49mi130°
RW30
 EMUN3B63mi8°
 IKLA3A104mi210°

STAR starting pointsdistanceinbound heading
RW12
 ESTA4A17.978°
 EMUN3A17.9154°
RW30
 VARC3B18.8205°
 TARTA119.8336°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW12CL610 (138°)CL610 3000ft
IGROS (6mi, 186°) 1500ft
RW12CL611 (92°)CL611 3000ft
IGROS (6mi, 48°) 1500ft
 RNAVIGROS 1500ft
CL615 (5mi, 114°) 1500ft
MUCL (5mi, 115°) 57ft
(4933mi, 105°) 1500ft
IKLAL (4940mi, 285°)
IKLAL (turn)
RW30CL620 (266°)CL620 3000ft
PELAO (6mi, 208°) 1500ft
RW30CL621 (324°)CL621 3000ft
PELAO (6mi, 28°) 1500ft
 RNAVPELAO 1500ft
BISPI (5mi, 295°) 1500ft
MUCL (5mi, 294°) 60ft
(4933mi, 105°) 1500ft
IKLAL (4940mi, 285°)
IKLAL (turn)

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
EMUN3AEMUNOVHFright18 (198)°4000ft - 14000ftDME 4.2mi230
ESTA4AESTASVHFright227 (47)°4000ft - 14000ftDME 4.2mi230
TARTA1TARTAVHFright180 (0)°4000ft - 14000ftDME 4.2mi230
VARC3BVARCAVHFright351 (171)°4000ft - 14000ftDME 4.2mi230
*) magnetic outbound (inbound) holding course
