Kiev - Kiev - Boryspil

Airport details

CountryUkraine
StateKyiv Oblast
RegionUK
AirspaceKyiv Ctr
MunicipalityГірська сільська громада
Elevation416ft (127m)
TimezoneGMT +2
Coordinates50.34472, 30.89333
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUKBB
IATA codeKBP
FAA coden/a

Communication

Kiev - Boryspil UKBB ATIS125.950
Kiev - Boryspil BORISPIL DLV130.275
Kiev - Boryspil BORISPIL Ground Control118.050
Kiev - Boryspil BORYSPIL Tower119.300
Kiev - Boryspil BORYSPIL Tower119.650
Kiev - Boryspil BORYSPIL Tower124.000
Kiev - Boryspil BORYSPIL Approach122.775
Kiev - Boryspil BORYSPIL Approach124.675
Kiev - Boryspil BORYSPIL Approach127.725
Kiev - Boryspil BORYSPIL Departure124.675
Kiev - Boryspil BORYSPIL Departure128.175
Kiev - Boryspil BORYSPIL Departure127.725

Approach frequencies

ILS-cat-IIIRW36R109.718.00mi
ILS-cat-IRW18L111.318.00mi
ILS-cat-IRW18R108.918.00mi
ILS-cat-IRW36L110.518.00mi
3° GSRW18L111.318.00mi
3° GSRW18R108.918.00mi
3° GSRW36L110.518.00mi
3° GSRW36R109.718.00mi
Nearby Points of Interest:
The South Tower (Kyiv Pechersk Lavra)
-
1 Ivana Mazepy Street
-
2/34 Saksahanskoho Street, Kiev
-
5 Saksahanskoho Street, Kiev
-
13/42 Saksahanskoho Street, Kiev
-
Holubovskyi estate, Kyiv
-
12 Saksahanskoho Street, Kiev
-
25 Saksahanskoho Street, Kiev
-
20 Saksahanskoho Street, Kiev
-
27 Saksahanskoho Street, Kiev
-
22 Saksahanskoho Street, Kiev
-
31/27 Saksahanskoho Street, Kiev
-
24/25 Saksahanskoho Street, Kiev
-
33-35/30 Saksahanskoho Street, Kiev
-
28 Saksahanskoho Street, Kiev
-
30 Saksahanskoho Street, Kiev
-
12-14 Bohdana Khmelnytskoho Street, Kiev
-
14 Mala Zhytomyrska Street, Kiev

Runway info

Runway 18R / 36L
 length3498m (11476ft)
 bearing184° / 4°
 width63m (207ft)
 surfaceconcrete
Runway 18L / 36R
 length4008m (13150ft)
 bearing184° / 4°
 width60m (197ft)
 surfaceconcrete

Nearby beacons

codeidentifierdistbearingfrequency
BBORYSPIL (KYIV) NDB1.1329°405
IBORYSPIL (KYIV) NDB1.530°640
OBORYSPIL (KYIV) NDB1.7161°640
EBORYSPIL (KYIV) NDB2204°405
KBBORYSPIL (KYIV) NDB2.5347°825
BIBORYSPIL (KYIV) NDB3.217°310
NOBORYSPIL (KYIV) NDB3.4172°310
BRPBORYSPIL (KYIV) VOR/DME3.5173°115.90
KEBORYSPIL (KYIV) NDB3.7195°825
BOBOHDANIVKA NDB17360°
ZKZHULIANY (KYIV) NDB18.4277°733
WANTONOV-1 (KYIV) NDB22286°376
CYCHERVONYI NDB25.3119°960
GOANTONOV-2 (KYIV) NDB28.5288°590
OANTONOV-2 (KYIV) NDB29.7289°286
CANTONOV-2 (KYIV) NDB32.2291°257
LCANTONOV-2 (KYIV) NDB33.6293°534
YHTDME34.895°117
KSNDME36.2108.60
STBDME56.8169°113

Departure and arrival routes

Transition altitude10007ft
SID end pointsdistanceoutbound heading
RW18L
 TUVO2A, TUVO2Z36mi
 KURO3Z, KURO2A42mi66°
 GOTA2A, GOTA2Z36mi96°
 BASO1A, BASO1Z18mi192°
 VESE3Z, VESE3A62mi240°
 SLV2A, SLV2Z52mi263°
 KAFE1A, KAFE1Z64mi279°
 BO2A, BO3Z17mi360°
RW18R
 TUVO2Y, TUVO2B36mi
 KURO3Y, KURO2B42mi66°
 GOTA2B, GOTA2Y36mi96°
 BASO1B, BASO1Y18mi192°
 VESE3Y, VESE3B62mi240°
 SLV2B, SLV2Y52mi263°
 KAFE1Y, KAFE1B64mi279°
 BO2B, BO3Y17mi360°
RW36L
 TUVO2S, TUVO2D36mi
 KURO3S, KURO2D42mi66°
 GOTA2D, GOTA2S36mi96°
 BASO1D, BASO1S18mi192°
 VESE3D, VESE3S62mi240°
 SLV2S, SLV2D52mi263°
 KAFE1S, KAFE1D64mi279°
 BO3S, BO2D17mi360°
RW36R
 TUVO2C, TUVO2R36mi
 KURO2C, KURO3R42mi66°
 GOTA2R, GOTA2C36mi96°
 BASO1C, BASO1R18mi192°
 VESE2R, VESE3C62mi240°
 SLV2R, SLV2C52mi263°
 KAFE1R, KAFE1C64mi279°
 BO3R, BO2C17mi360°

STAR starting pointsdistanceinbound heading
RW18L
 SULU4U47.814°
 SLV2U, SLV2E51.683°
 NANI2E, NANI4U37.9128°
 KUVA2E, KUVA4U88.2184°
 NEMI2E, NEMI4U117.8221°
 GOTA2E, GOTA2U35.9276°
 VEBI2E, VEBI2U48.3298°
 KONI4U, KONI2E41.7317°
RW18R
 SULU1J47.814°
 SLV2J, SLV2T51.683°
 NANI1J, NANI4T37.9128°
 KUVA1J, KUVA4T88.2184°
 NEMI4T, NEMI1J117.8221°
 GOTA2T, GOTA2J35.9276°
 VEBI1J, VEBI2T48.3298°
 KONI4T, KONI1J41.7317°
RW36L
 SULU4V, SULU1Q47.814°
 SLV2Q, SLV2V51.683°
 NANI2Q, NANI4V37.9128°
 KUVA2Q, KUVA4V88.2184°
 NEMI4V, NEMI2Q117.8221°
 GOTA2V, GOTA2Q35.9276°
 VEBI2V, VEBI1Q48.3298°
 KONI4V, KONI2Q41.7317°
RW36R
 SULU4W47.814°
 SLV2W, SLV2F51.683°
 NANI2F, NANI4W37.9128°
 KUVA2F, KUVA4W88.2184°
 NEMI2F, NEMI4W117.8221°
 GOTA2W, GOTA2F35.9276°
 VEBI2F, VEBI2W48.3298°
 KONI4W, KONI2F41.7317°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
CY1ECYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1JCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1TBB440VHFright356 (176)°> 2960ft1.0min timed220
CY1TCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1UBB440VHFright356 (176)°> 2960ft1.0min timed220
CY1UCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1VBB640VHFright176 (356)°> 2960ft1.0min timed220
CY1VCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY1WBB640VHFright176 (356)°> 2960ft1.0min timed220
CY1WCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
CY2QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
GOTA2EGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
GOTA2FGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2JGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
GOTA2QGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2TBB440VHFright356 (176)°> 2960ft1.0min timed220
GOTA2TGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2UBB440VHFright356 (176)°> 2960ft1.0min timed220
GOTA2UGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2VBB640VHFright176 (356)°> 2960ft1.0min timed220
GOTA2VGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
GOTA2WBB640VHFright176 (356)°> 2960ft1.0min timed220
GOTA2WGOTAPVHFleft86 (266)°> 6070ft1.0min timedICAO rules
KONI1JCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI1JKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI2ECYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI2EKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI2FKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI2QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI2QKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI4TBB440VHFright356 (176)°> 2960ft1.0min timed220
KONI4TCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI4TKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI4UBB440VHFright356 (176)°> 2960ft1.0min timed220
KONI4UCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI4UKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI4VBB640VHFright176 (356)°> 2960ft1.0min timed220
KONI4VCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI4VKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KONI4WBB640VHFright176 (356)°> 2960ft1.0min timed220
KONI4WCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KONI4WKONIPVHFleft140 (320)°> 6070ft1.0min timedICAO rules
KUVA1JBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
KUVA2EBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
KUVA2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KUVA2QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
KUVA4TBB440VHFright356 (176)°> 2960ft1.0min timed220
KUVA4TBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
KUVA4UBB440VHFright356 (176)°> 2960ft1.0min timed220
KUVA4UBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
KUVA4VBB640VHFright176 (356)°> 2960ft1.0min timed220
KUVA4VBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
KUVA4WBB640VHFright176 (356)°> 2960ft1.0min timed220
KUVA4WBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
NANI1JBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
NANI1JNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI2EBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
NANI2ENANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI2FNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI2QNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI4TBB440VHFright356 (176)°> 2960ft1.0min timed220
NANI4TNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI4UBB440VHFright356 (176)°> 2960ft1.0min timed220
NANI4UNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI4VBB640VHFright176 (356)°> 2960ft1.0min timed220
NANI4VNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NANI4WBB640VHFright176 (356)°> 2960ft1.0min timed220
NANI4WNANIRVHFleft312 (132)°> 3940ft1.0min timedICAO rules
NEMI1JBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
NEMI2EBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
NEMI2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
NEMI2QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
NEMI4TBB440VHFright356 (176)°> 2960ft1.0min timed220
NEMI4TBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
NEMI4UBB440VHFright356 (176)°> 2960ft1.0min timed220
NEMI4UBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
NEMI4VBB640VHFright176 (356)°> 2960ft1.0min timed220
NEMI4VBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
NEMI4WBB640VHFright176 (356)°> 2960ft1.0min timed220
NEMI4WBBN01VHFleft13 (193)°> 6070ft1.0min timedICAO rules
SLV2EBOFIXleft346 (166)°> 2960ft1.0min timedICAO rules
SLV2ESLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2FSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2JSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2QSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2TBB440VHFright356 (176)°> 2960ft1.0min timed220
SLV2TSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2UBB440VHFright356 (176)°> 2960ft1.0min timed220
SLV2USLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2VBB640VHFright176 (356)°> 2960ft1.0min timed220
SLV2VSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SLV2WBB640VHFright176 (356)°> 2960ft1.0min timed220
SLV2WSLVNDBleft230 (50)°> 6070ft1.0min timedICAO rules
SULU1JCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU1JSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU1QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU1QSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU2ECYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU2ESULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU2FSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU2TBB440VHFright356 (176)°> 2960ft1.0min timed220
SULU2TCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU2TSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU4UBB440VHFright356 (176)°> 2960ft1.0min timed220
SULU4UCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU4USULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU4VBB640VHFright176 (356)°> 2960ft1.0min timed220
SULU4VCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU4VSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
SULU4WBB640VHFright176 (356)°> 2960ft1.0min timed220
SULU4WCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
SULU4WSULUMVHFright184 (4)°> 6070ft1.0min timedICAO rules
VEBI1JCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI1JVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI1QCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI1QVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2ECYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI2EVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2FCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI2FVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2TBB440VHFright356 (176)°> 2960ft1.0min timed220
VEBI2TVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2UBB440VHFright356 (176)°> 2960ft1.0min timed220
VEBI2UVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2VBB640VHFright176 (356)°> 2960ft1.0min timed220
VEBI2VCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI2VVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
VEBI2WBB640VHFright176 (356)°> 2960ft1.0min timed220
VEBI2WCYFIXright122 (302)°> 3940ft1.0min timedICAO rules
VEBI2WVEBIXVHFleft120 (300)°> 6070ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course

Disclaimer

The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
