Country | Ukraine |
State | Vinnytsia Oblast |
Region | UK |
Airspace | Kyiv Ctr |
Municipality | Vinnytsia Urban Hromada |
Elevation | 973ft (297m) |
Timezone | GMT +2 |
Coordinates | 49.23694, 28.61893 |
Magnetic var | |
Type | land |
Available since | X-Plane v10.40 |
ICAO code | UKWW |
IATA code | VIN |
FAA code | n/a |
Vinnytsia Intl UKWW_Tower | 128.000 |
ILS-cat-I | RW31 | 110.3 | 18.00mi |
3° GS | RW31 | 110.3 | 18.00mi |
code | identifier | dist | bearing | frequency |
---|---|---|---|---|
VIN | DME | 0.1 | 34° | 113.90 |
N | GAVRYSHIVKA (VINNYTSIA) NDB | 0.8 | 120° | 842 |
I | GAVRYSHIVKA (VINNYTSIA) NDB | 1.5 | 308° | 842 |
WN | GAVRYSHIVKA (VINNYTSIA) NDB | 2.5 | 124° | 415 |
WI | GAVRYSHIVKA (VINNYTSIA) NDB | 3.2 | 307° | 415 |
SLV | SOLOVIIVKA VOR/DME | 67.9 | 45° | 113.30 |
Transition altitude | 10007ft |
SID end points | distance | outbound heading | |
---|---|---|---|
RW13 | |||
POGE6A | 29mi | 61° | |
NIRO2A | 19mi | 140° | |
TAKE5A | 35mi | 251° | |
KORO4G | 31mi | 264° | |
RW31 | |||
POGE6C | 29mi | 61° | |
NIRO2B | 19mi | 140° | |
TAKE4G | 35mi | 251° | |
KORO6B | 31mi | 264° |
STAR starting points | distance | inbound heading | |
---|---|---|---|
RW13 | |||
TAKE4H | 34.5 | 71° | |
KORO6C | 30.8 | 84° | |
POGE6D | 28.9 | 241° | |
NIRO2C | 18.6 | 320° | |
RW31 | |||
TAKE4D | 34.5 | 71° | |
KORO4H | 30.8 | 84° | |
POGE6E | 28.9 | 241° | |
NIRO2D | 18.6 | 320° |
STAR name | hold at | type | turn | heading* | altitude | leg | speed limit |
---|---|---|---|---|---|---|---|
KORO4H | WN | FIX | left | 132 (312)° | > 3120ft | 1.0min timed | ICAO rules |
KORO6C | WI | FIX | right | 312 (132)° | > 3120ft | 1.0min timed | ICAO rules |
NIRO2C | WI | FIX | right | 312 (132)° | > 3120ft | 1.0min timed | ICAO rules |
NIRO2D | WN | FIX | left | 132 (312)° | > 3120ft | 1.0min timed | ICAO rules |
POGE6D | WI | FIX | right | 312 (132)° | > 3120ft | 1.0min timed | ICAO rules |
POGE6E | WN | FIX | left | 132 (312)° | > 3120ft | 1.0min timed | ICAO rules |
TAKE4D | WN | FIX | left | 132 (312)° | > 3120ft | 1.0min timed | ICAO rules |
TAKE4H | WI | FIX | right | 312 (132)° | > 3120ft | 1.0min timed | ICAO rules |
*) magnetic outbound (inbound) holding course |
The information on this website is not for real aviation. Use this data with the X-Plane flight simulator only! Data taken with kind consent from X-Plane 12 source code and data files. Content is subject to change without notice.
