Airports for X-Plane

Kostanay

Airport details

CountryKazakhstan
StateKostanay Region
RegionUA
AirspaceNur-sultan Ctr
MunicipalityKostanay
Elevation601ft (183m)
TimezoneGMT +6
Coordinates53.20861, 63.54805
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeUAUU
IATA codeKSN
FAA coden/a

Communication

Kostanay Kostanay ATIS127.500
Kostanay Kostanay Tower129.300

Approach frequencies

ILS-cat-IRW33110.718.00mi
2.7° GSRW33110.718.00mi

Runway info

Runway 15R / 33L
 length2550m (8366ft)
 bearing145° / 325°
 width70m (230ft)
 surfacegrass
Runway 15 / 33
 length2812m (9226ft)
 bearing145° / 325°
 width45m (148ft)
 surfaceconcrete
 displ threshold302m (991ft) / 0m (0ft)
 blast zone60m (197ft) / 60m (197ft)

Airport layout - parking location 1


Taxiway locations

 A  B  C  D  E  F
Parking locations

 1  2  3  4  5  6  7  8
 9

Nearby beacons

codeidentifierdistbearingfrequency
NKOSTANAY NDB1.2145°250
KSTKOSTANAY VOR/DME1.4146°114.80

Departure and arrival routes

Transition altitude10000ft
SID end pointsdistanceoutbound heading
RW15
 NELT5C, NELT2E72mi33°
 AKOS5C, AKOS2E65mi73°
 BIMS5C, BIMS2E65mi88°
 DOKU2E, DOKU5C65mi104°
 UNIB1C, UNIB1E62mi128°
 ARDI2E, ARDI4C65mi139°
 BALO2E, BALO3C60mi159°
 BUDE2E, BUDE5C60mi191°
 DOPA6C, DOPA2E65mi213°
 BAMI2E, BAMI5C65mi247°
 TITU5C, TITU2E87mi275°
 LANO2E, LANO5C61mi315°
RW33
 NELT4D, NELT2F72mi33°
 AKOS4D, AKOS2F65mi73°
 BIMS2F, BIMS4D65mi88°
 DOKU4D, DOKU2F65mi104°
 UNIB1D, UNIB1F62mi128°
 ARDI2F, ARDI4D65mi139°
 BALO2F, BALO3D60mi159°
 BUDE2F, BUDE4D60mi191°
 DOPA5D, DOPA2F65mi213°
 BAMI2F, BAMI4D65mi247°
 TITU2F, TITU4D87mi275°
 LANO2F, LANO4D61mi315°

STAR starting pointsdistanceinbound heading
RW15
 BUDE5A, BUDE2G59.811°
 DOPA2G, DOPA6A64.733°
 BAMI2G, BAMI5A64.667°
 TITU5A, TITU2G86.595°
 LANO5A, LANO2G61.4135°
 NELT5A, NELT2G72.0213°
 AKOS2G, AKOS5A64.6253°
 BIMS5A, BIMS2G64.6268°
 DOKU5A, DOKU2G64.7284°
 UNIB1G, UNIB1A61.7308°
 ARDI2G, ARDI5A64.8319°
 BALO4A, BALO2G59.9339°
RW33
 BUDE4B, BUDE2H59.811°
 DOPA5B, DOPA2H64.733°
 BAMI2H, BAMI4B64.667°
 TITU4B, TITU2H86.595°
 LANO4B, LANO2H61.4135°
 NELT2H, NELT4B72.0213°
 AKOS2H, AKOS4B64.6253°
 BIMS2H, BIMS4B64.6268°
 DOKU4B, DOKU2H64.7284°
 UNIB1B, UNIB1H61.7308°
 ARDI4B, ARDI2H64.8319°
 BALO3B, BALO2H59.9339°

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
AKOS2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
AKOS2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
AKOS4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
AKOS5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
ARDI2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
ARDI2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
ARDI4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
ARDI5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BALO2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BALO2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BALO3BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BALO4ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BAMI2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BAMI2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BAMI4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BAMI5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BIMS2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BIMS2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BIMS4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BIMS5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BUDE2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BUDE2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
BUDE4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
BUDE5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
DOKU2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
DOKU2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
DOKU4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
DOKU5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
DOPA2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
DOPA2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
DOPA5BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
DOPA6ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
LANO2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
LANO2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
LANO4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
LANO5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
NELT2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
NELT2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
NELT4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
NELT5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
TITU2GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
TITU2HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
TITU4BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
TITU5ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
UNIB1ANVHFleft346 (166)°> 7000ft1.0min timedICAO rules
UNIB1BNVHFleft346 (166)°> 7000ft1.0min timedICAO rules
UNIB1GKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
UNIB1HKSTNDBright325 (145)°> 4000ft1.0min timedICAO rules
*) magnetic outbound (inbound) holding course
