Airports for X-Plane

Nha Trang - Cam Ranh

Airport details

CountryVietnam
StateKhánh Hòa Province
RegionVV
AirspaceHo Chi Minh Ctr
MunicipalityCam Ranh city
Elevation40ft (12m)
TimezoneGMT +7
Coordinates11.99546, 109.21841
Magnetic var
Typeland
Available sinceX-Plane v10.40
ICAO codeVVCR
IATA codeCXR
FAA coden/a

Communication

Cam Ranh Tower118.200
Cam Ranh Approach127.900

Approach frequencies

ILS-cat-IRW20L110.318.00mi
ILS-cat-IRW02L110.718.00mi
ILS-cat-IRW02R111.918.00mi
3.5° GSRW02L110.718.00mi
3.5° GSRW02R111.918.00mi
3° GSRW20L110.318.00mi

Runway info

Runway 02L / 20R
 length3063m (10049ft)
 bearing19° / 199°
 width46m (150ft)
 surfaceconcrete
 blast zone255m (837ft) / 255m (837ft)
Runway 02R / 20L
 length3057m (10030ft)
 bearing19° / 199°
 width45m (148ft)
 surfaceconcrete

Airport layout - taxiway location A5


Taxiway locations

 A1  A3  A4  A5
Parking locations

 1  10  11  14  15  16  17  1g
 2  2g  3  3g  4  4g  5  5g
 6  6g  7  7g  8  8g  9  9b
 New

Nearby beacons

codeidentifierdistbearingfrequency
CRACAM RANH VOR/DME0.1123°116.50
CRCAM RANH NDB0.3337°414
LKHLIEN KHUONG VOR/DME52.7254°112.30
HYDDALAT NDB53.8255°312
DLDALAT NDB57.9255°330

Departure and arrival routes

Transition altitude9030ft
Transition level10000ft
SID end pointsdistanceoutbound heading
RW02 (ALL)
 NITO1A95mi62°
 PTH1A16mi227°
 DALA1A16mi255°
 KARA1B, KARA1A39mi355°
RW02L
 FURA1A, NITO1C95mi62°
 PTH1C16mi227°
 DALA1C16mi255°
 PANL1A41mi302°
 NIHO1A22mi355°
 KARA1E, KARA1D39mi355°
RW02R
 FURA1A95mi62°
 PANL1A41mi302°
 NIHO1A22mi355°
RW20 (ALL)
 NITO1B95mi62°
 PTH1B16mi227°
 DALA1B16mi255°
 KARA1C39mi355°
RW20L
 KOPO1A95mi62°
 ANKI1B22mi227°
 BANK1B22mi254°
 SOTE1B22mi302°
 NIHO1B22mi355°
RW20R
 NITO1D, KOPO1A95mi62°
 ANKI1B22mi227°
 PTH1D16mi227°
 BANK1B22mi254°
 DALA1D16mi255°
 SOTE1B22mi302°
 NIHO1B22mi355°
 KARA1F39mi355°

STAR starting pointsdistanceinbound heading
ALL
 SUID1A16.247°
 PANC1A16.175°
 NHAT1A13.9176°
 PHUS1A16.2242°
RW02 (ALL)
 ANKI1A21.647°
 BANK1A21.574°
 COTU2A21.7197°
 HUNT2A21.6242°
RW02L
 NHAT1C13.9176°
RW20 (ALL)
 BANK1C21.574°
 PANL1B21.6150°
 COTU3B21.7197°
 HUNT2B21.6242°
RW20R
 SUID1B16.247°
 PANC1B16.175°
 NHAT1B13.9176°
 PHUS1B16.2242°

Instrument approach procedures

runwayairway (heading)route (dist, bearing)
RW02LYCR220 (295°)CR220 4000ft
CR021 (16mi, 258°)
CR022 (8mi, 296°) 2600ft
 RNAVCR022 2600ft
CR023 (3mi, 19°) 2140ft
MR02L (4mi, 19°) 583ft
CR218 (5mi, 19°)
CR219 (12mi, 83°) 4000ft
CR220 (15mi, 153°) 4000ft
CR220 (turn) 4000ft
RW02LZCR021 (342°)CR021 5000ft
CR022 (8mi, 296°) 2600ft
 RNAVCR022 2600ft
CR023 (3mi, 19°) 2140ft
MR02L (4mi, 19°) 583ft
CR218 (5mi, 19°)
CR219 (12mi, 83°) 4000ft
CR220 (15mi, 153°) 4000ft
CR220 (turn) 4000ft
RW02RYCR220 (295°)CR220 4000ft
CR021 (16mi, 258°)
CR822 (8mi, 296°) 2610ft
 RNAVCR822 2610ft
CR823 (3mi, 19°) 2140ft
VVCR (6mi, 18°) 69ft
CR818 (4mi, 21°)
CR219 (11mi, 89°) 4000ft
CR220 (15mi, 153°) 4000ft
CR220 (turn) 4000ft
RW02RZCR021 (342°)CR021 5000ft
CR822 (8mi, 296°) 2610ft
 RNAVCR822 2610ft
CR823 (3mi, 19°) 2140ft
VVCR (6mi, 18°) 69ft
CR818 (4mi, 21°)
CR219 (11mi, 89°) 4000ft
CR220 (15mi, 153°) 4000ft
CR220 (turn) 4000ft
RW20LYCR223 (299°)CR223 4000ft
CR201 (21mi, 336°)
CR293 (7mi, 288°) 3120ft
 RNAVCR293 3120ft
CR294 (4mi, 199°) 2140ft
VVCR (7mi, 200°) 84ft
CR295 (4mi, 197°) 2000ft
CR222 (15mi, 133°)
CR223 (10mi, 68°) 4000ft
CR223 (turn) 4000ft
RW20LZCR201 (230°)CR201 5000ft
CR293 (7mi, 288°) 3120ft
RW20LZCR202 (199°)CR202 4000ft
CR293 (4mi, 197°) 3120ft
RW20LZCR209 (159°)CR209 6000ft
CR293 (10mi, 108°) 3120ft
 RNAVCR293 3120ft
CR294 (4mi, 199°) 2140ft
VVCR (7mi, 200°) 84ft
CR295 (4mi, 197°) 2000ft
CR222 (15mi, 133°)
CR223 (10mi, 68°) 4000ft
CR223 (turn) 4000ft
RW20RYCR223 (299°)CR223 4000ft
CR201 (21mi, 336°)
CR203 (7mi, 289°) 3100ft
 RNAVCR203 3100ft
CR204 (4mi, 199°) 2140ft
VVCR (7mi, 199°) 96ft
CR205 (4mi, 199°) 2000ft
CR222 (15mi, 133°)
CR223 (10mi, 68°) 4000ft
CR223 (turn) 4000ft
RW20RZCR201 (230°)CR201 5000ft
CR203 (7mi, 289°) 3100ft
RW20RZCR202 (199°)CR202 4000ft
CR203 (4mi, 199°) 3100ft
RW20RZCR209 (159°)CR209 6000ft
CR203 (10mi, 108°) 3100ft
 RNAVCR203 3100ft
CR204 (4mi, 199°) 2140ft
VVCR (7mi, 199°) 96ft
CR205 (4mi, 199°) 2000ft
CR222 (15mi, 133°)
CR223 (10mi, 68°) 4000ft
CR223 (turn) 4000ft

Holding patterns

STAR namehold attypeturnheading*altitudelegspeed limit
ANKI1AANKINVHFright232 (52)°9000ft - 14000ft1.0min timed230
ANKI1ACR021VHFleft117 (297)°5000ft - 14000ft1.0min timed230
BANK1ABANKEVHFleft261 (81)°11000ft - 14000ft1.0min timed230
BANK1ACR021VHFleft117 (297)°5000ft - 14000ft1.0min timed230
BANK1CBANKEVHFleft261 (81)°11000ft - 14000ft1.0min timed230
BANK1CCR209VHFleft289 (109)°6000ft - 14000ft1.0min timed230
COTU2ACR021VHFleft117 (297)°5000ft - 14000ft1.0min timed230
COTU2ASIMMEVHFleft355 (175)°12000ft - 14000ft1.0min timed230
COTU3BCR202VHFleft19 (199)°4000ft - 14000ft1.0min timed230
COTU3BSIMMEVHFleft355 (175)°12000ft - 14000ft1.0min timed230
HUNT2ACR021VHFleft117 (297)°5000ft - 14000ft1.0min timed230
HUNT2ALIGUNVHFleft63 (243)°14000ft - 14000ft1.0min timed230
HUNT2BCR201VHFright110 (290)°5000ft - 14000ft1.0min timed230
HUNT2BLIGUNVHFleft63 (243)°14000ft - 14000ft1.0min timed230
PANL1BCHUTUVHFleft277 (97)°11000ft - 14000ft1.0min timed230
PANL1BCR209VHFleft289 (109)°6000ft - 14000ft1.0min timed230
SOTE1ABIDAMVHFleft303 (123)°8000ft - 14000ft1.0min timed230
SOTE1ACR021VHFleft117 (297)°5000ft - 14000ft1.0min timed230
*) magnetic outbound (inbound) holding course
